Raisecom iTN2100 - Table 21-33 PIN of the HDB26 Interface on the OPCOM3500 E-4 V35

Raisecom
iTN2100 (P100R002) Hardware Description
21 Cables
Raisecom Technology Co., Ltd.
270
PIN
Defined output for way 1 of
V.35 data
Defined output for way 2 of
V.35 data
10
TD (A)
11
TD (B)
12
SCTE (A)
13
SCTE (B)
14
TCP (A)
15
TCP (A)
16
SCTE (B)
17
RCP (A)
18
PGND
19
TD (B)
20
–
–
21
RD (B)
22
TCP (B)
23
TCP (B)
24
SCTE (A)
25
RCP (B)
26
GND
The PINs marked "–" are idle.
OPCOM3500E-4V35
There are four HDB26 female interfaces on the OPCOM3500E-4V35. Each interface
transmits a way of V.35 data with handshaking signals. You can make cables according to
Table 21-33.
Table 21-33 PIN of the HDB26 interface on the OPCOM3500E-4V35
PIN
Defined mark of V.35
ISO2593 (M34 female connector)
1
PGND
A
2
TD(A)
P
3
RD(A)
R
4
RTS
C
