iTN2100 (P100R002) Hardware Description
13 EOP cards
Raisecom Technology Co., Ltd.
102
Interface
Status
Description
LNK/ACT
(1–8)
Green
Link working LED

Green: the link interface is properly connected.

Off: the link interface improperly connected or disconnected.

Blinking green: the link interface is receiving or sending data.
13.6.5 Alarms
Table 13-29 lists alarms of the OPCOM3500E-EOP-FXE1×8.
Table 13-29 Alarms of the OPCOM3500E-EOP-FXE1×8
Alarm
Cause
Level
SFP absence alarm

The SFP optical module is removed.

The SFP optical module is improperly
installed.

The SFP optical module fails.
Critical
SFP sending failure alarm
The SFP optical module fails.
Critical
SFP receiving LOS alarm

Attenuation of received signals is over great.

The peer sender fails.

The fiber head is unclean or the connector is
improperly connected.

The local receiver fails.
Critical
E1 AIS alarm
E1 signals are composed of "1" only, because
transmission fails or the peer device outputs
AIS signals.
Minor
E1 LOF alarm
The output data of uplink devices is incorrect,
because services are improperly configured or
hardware fails.
Critical
E1 CRC alarm
Data error occurs in transmission.
Critical
Ethernet interface link down
alarm

Fiber is disconnected.

The RX and TX of the peer device fail.
Critical
LPR alarm on the peer
device
The remote transceiver is powered off.
Critical
13.6.6 Specifications
Table 13-30 lists specifications of the OPCOM3500E-EOP-FXE1×8.
Table 13-30 Specifications of the OPCOM3500E-EOP-FXE1×8
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
