14.2.3 Interfaces
Interface types
There are eight interfaces on the OPCOM3500E-EOS-8FE panel, as listed in Table 14-6.
Table 14-6 Interfaces on the OPCOM3500E-EOS-8FE panel
Interface
Type
Description
–
RJ45
8 FE interfaces
Interface parameters
Table 14-7 lists parameters of FE electrical interfaces on the OPCOM3500E-EOS-8FE.
Table 14-7 Parameters of FE electrical interfaces on the OPCOM3500E-EOS-8FE
Parameter
Description
Connector type
RJ45
Interface rate
10/100 Mbit/s or auto-negotiation
14.2.4 LEDs
There are 11 LEDs on the OPCOM3500E-EOS-8FE panel, as listed in Table 14-8.
Table 14-8 LEDs on the OPCOM3500E-EOS-8FE panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
ALM
Red
Alarm LED

Red: TU-AIS or TU-LOP alarms are generated in the lower
order path of service allocation.

Off: no TU-AIS or TU-LOP alarms are generated in the
lower order path of service allocation.
100M
(1–8)
Green
Ethernet electrical interface rate LED

Green: the interface is working at 100 Mbit/s.

Off: the interface is working at 10 Mbit/s.
