iTN2100 (P100R002) Hardware Description
7 SDH tributary cards
Raisecom Technology Co., Ltd.
44
Alarm
Cause
Level
MS-AIS
Multiplexing section alarm LED

Alarm signals are inserted in the optical signals sent by the
peer device.

The peer device is a regenerator and receives LOS, LOF, or
OOF alarms.
Minor
HP-LOM
High order path Loss of Multiframe (LOM) alarm

Services are improperly configured.

Byte H4 is lost or incorrect.
Critical
HP-TIM

The received channel trace byte of the local device and the
sent channel trace byte of the peer device are inconsistent.

Services are improperly configured.
Critical
HP-PLM

The received signal marking byte of the local device and the
sent signal marking byte of the peer device are inconsistent.

Services are improperly configured.
Critical
TU-AIS

Services are improperly configured.

The channel of the peer device fails.

Higher order path alarms, such as R-LOS, trigger the alarm.

The cross connection card fails.
Minor
TU-LOP

The interface between the tributary card and the cross
connection card fails.

Services are improperly configured.
Critical
LP-TIM

The LP trace identifiers of the local device and the peer
device are inconsistent.

Services are improperly configured.
Critical
7.2.6 Specifications
Table 7-13 lists specifications of the OPCOM3500E-4STM1-S.
Table 7-13 Specifications of the OPCOM3500E-4STM1-S
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.45 kg
Max. power consumption
8.4 W
