Raisecom
iTN2100 (P100R002) Hardware Description
11 Clock card
Raisecom Technology Co., Ltd.
76
Table 11-5 LEDs on the iTN2100-TSU panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
LOCK
Red
Lockout state LED

Red: the current 1588 V2 time is in unlock state.

Off: the current 1588 V2 time is in lockout state.
ALM
Red
Fault alarm LED

Red: LOS alarms are generated on current 2-way external
clock signals. The ALM LED is off when at least one-way
signal is displayed as normal/lof.

Off: currently, at least one-way external clock signal is input
properly.
11.1.5 Specifications
Table 11-6 lists specifications of the iTN2100-TSU.
Table 11-6 Specifications of the iTN2100-TSU
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.4 kg
Max. power consumption
20 W
