iTN2100 (P100R002) Hardware Description
16 V.24 card
Raisecom Technology Co., Ltd.
16-195
Interface
Status
Description
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
TD
(1–8)
Green

Blinking green: V.24 data channel interface 1/2/.../7/8 is sending
data from itself to the DTE device. Blinking frequency indicates
transmission rate.

Off: V.24 data channel interface 1/2/.../7/8 is not sending data.
RD
(1–8)
Green

Blinking green: V.24 data channel interface 1/2/.../7/8 is
receiving data from the DTE device to itself. Blinking frequency
indicates transmission rate.

Off: V.24 data channel interface 1/2/.../7/8 is not receiving data.
16.1.5 Cables
Table 16-4 lists cables of the OPCOM3500E-8V24.
Table 16-4 Cables of the OPCOM3500E-8V24
Card
Cable
OPCOM3500E-8V24

CBL-V24-HDB26M/4DB25F

CBL-V24-HDB26M/4DB25M
16.1.6 Specifications
Table 16-5 lists specifications of the OPCOM3500E-8V24.
Table 16-5 Specifications of the OPCOM3500E-8V24
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
< 0.45 kg
Max. power consumption
4 W
