iTN2100 (P100R002) Hardware Description
12 TDMoP card
Raisecom Technology Co., Ltd.
80
Table 12-3 LEDs on the iTN2100-CES-16E1T1-BL panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
LOS
(1–16)
Red
LOS alarm LED

Red: LOS alarms are generated on E1 services.

Off: no LOS alarm is generated on E1 services.
12.1.5 Specifications
Table 12-4 lists specifications of the iTN2100-CES-16E1T1-BL.
Table 12-4 Specifications of the iTN2100-CES-16E1T1-BL
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.45 kg
Max. power consumption
15 W
