iTN2100 (P100R002) Hardware Description
14 EOS cards
Raisecom Technology Co., Ltd.
129
Interface
Status
Description
ALM
Red
Alarm LED

Red: TU-AIS or TU-LOP alarm are generated in VC-12.

Off: no TU-AIS or TU-LOP alarm are generated in VC-
12.
100M
Green
Ethernet electrical interface working LED

Green: the interface is working at 100 Mbit/s.

Off: the interface is working at 10 Mbit/s or disconnected.
LNK
Green
Link working LED

Green: the link interface is properly connected.

Off: the link interface improperly connected or
disconnected.
FDX
Green
Duplex mode LED

Green: the Ethernet electrical interface is working in full
duplex mode.

Off: the Ethernet electrical interface is working in half
duplex mode.
ACT
Green
Data TX/RX LED

Green: the interface is receiving or sending data.

Off: the interface is not receiving or sending data.
14.4.5 DIP switches
Table 14-20 and Table 14-21 list configurations of DIP switches on the OPCOM3500E-
8EOS-FE.
Table 14-20 Configurations of DIP switch SW2 on the OPCOM3500E-8EOS-FE
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
SW2
Set the type
of the
optical
interface
device.
ON
ON
ON
ON
M
ON
ON
ON
OFF
S1
ON
ON
OFF
ON
S2
ON
ON
OFF
OFF
S3
ON
OFF
ON
ON
SS13
ON
OFF
ON
OFF
SS15
ON
OFF
OFF
ON
SS23
ON
OFF
OFF
OFF
SS25
