iTN2100 (P100R002) Hardware Description
20 Service aggregation cards
Raisecom Technology Co., Ltd.
225

Line-side interface metrics
Line-side interface metrics vary on the iTN2100 cards. Table 20-4 lists line-side interface
metrics.
Table 20-4 Line-side interface metrics
Ver
sion
Card model
TX
wavelength
(nm)
RX
wavelength
(nm)
Single-
wavelength TX
power (dBm)
Single-
wavelength
RX power
(dBm)
Transmis
sion
distance
(Km)
A
iTN2100-Gb-S
1471, 1511,
1551, 1591
1491, 1531,
1571,1611
-4 to +2
-20 to -2
40
iTN2100-Gb-S-R
1491, 1531,
1571,1611
1471, 1511,
1551, 1591
-4 to +2
-20 to -2
40
iTN2100-Gb-L
1471, 1511,
1551, 1591
1491, 1531,
1571,1611
-4 to +2
-28 to -8
80
iTN2100-Gb-L-R
1491, 1531,
1571,1611
1471, 1511,
1551, 1591
--4 to +2
-28 to -8
80
B
iTN2100-48-S
1471, 1511,
1551, 1591
1491, 1531,
1571,1611
-2 to +4
-16 to -2
40
iTN2100-48-S-R
1491, 1531,
1571,1611
1471, 1511,
1551, 1591
-2 to +4
-16 to -2
40
The single-wavelength RX power is the EOL value.
20.1.4 LEDs
There are 18 LEDs on the iTN2100-Gb panel, as listed in Table 20-5.
Table 20-5 LEDs on the iTN2100-Gb panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
