iTN2100 (P100R002) Hardware Description
14 EOS cards
Raisecom Technology Co., Ltd.
134
SW3
Function
Status
Description
DIP bit
Ethernet
services
OFF
Set the front plane interface to the egress
interface of Ethernet services.
Bit3
Reserved
Bit4
By default, Bit2 of SW3 is OFF.
14.5.6 Alarms
Table 14-29 lists alarms of the OPCOM3500E-8EOS-FX.
Table 14-29 Alarms of the OPCOM3500E-8EOS-FX
Alarm
Cause
Level
Alarm overall alarm
TU-AIS, TU-LOP
Critical
Optical signal LOS alarm
No optical signals are input.
Critical
Ethernet optical interface
link failure alarm

Fiber is disconnected.

The RX and TX of the remote device fail.
Critical
Remote device LPR alarm
The remote transceiver is powered off.
Critical
14.5.7 Specifications
Table 14-30 lists specifications of the OPCOM3500E-8EOS-FX.
Table 14-30 Specifications of the OPCOM3500E-8EOS-FX
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.4 kg
Max. power consumption
10 W
