15.8.4 LEDs
There are 20 LEDs on the OPCOM3500E-120FE×8L-GE panel, as listed in Table 15-44.
Table 15-44 LEDs on the OPCOM3500E-120FE×8L-GE panel
LED
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
1000M
(GE)
Green
Ethernet interface 1000 Mbit/s LED

Green: the Ethernet rate is 1000 Mbit/s.

Off: the Ethernet rate is 100 Mbit/s or the connection fails.
LNK/ACT
(GE)
Green
Ethernet interface working LED

Green: the Ethernet interface is properly connected.

Off: the Ethernet interface is disconnected.

Blinking green: the Ethernet interface is receiving or sending
data. The blinking frequency is related to the transmission rate.
LPR
(1–8)
Red
Optical interface remote device LPR alarm LED

Red: after the local device and the remote device connected to
the related optical interface work properly, LPR occurs on the
remote device.

Off: the remote device connected to the related optical
interface is working properly.
LOS
(1–8)
Red
Optical interface LOS alarm LED

Red: input LOS alarms are generated on the related optical
interface.

Blinking red: the related optical interface receives signals
properly while input LOS alarms are generated on the
connected device

Off: no input LOS alarms are generated on the related optical
interface and connected remote device.
15.8.5 Alarms
Table 15-45 lists alarms generated on the OPCOM3500E-120FE×8L-GE.
