13.8.3 Interfaces
Interface types
There are eight interfaces on the OPCOM3500E-EOP-FXE1×8 panel, as listed in Table 13-37.
Table 13-37 Interfaces on the OPCOM3500E-HT-6FE24E1 panel
Interface
Type
Description
1–6
RJ45
Six ways of EF electrical interfaces
DebugE and DebugC
RJ45
Debugging interfaces
Interface parameters
Table 13-38 lists parameters of interfaces 1–6 on the OPCOM3500E-HT-6FE24E1.
Table 13-38 Parameters of interfaces 1–6 on the OPCOM3500E-HT-6FE24E1
Parameter
Description
Connector type
RJ45
Interface rate
Support auto-negotiation (but in this mode it supports 100 Mbit/s full
duplex only).
Duplex mode
Full duplex
Flow control
IEEE 802.3x-based flow control in full duplex mode
Line order
Auto MDI/MDIX
13.8.4 LEDs
There are eight LEDs on the OPCOM3500E-HT-6FE24E1 panel, as listed in Table 13-39.
Table 13-39 LEDs on the OPCOM3500E-HT-6FE24E1 panel
Interface
Status
Description
PWR
Green
Power LED

Green: the power supply is normal.

Off: the power supply is abnormal.
SYS
Green
System status LED

Green: the system is working improperly.

Off: the system is working improperly.

Blinking green: the system is working properly.
