Raisecom
iTN2100 (P100R002) Hardware Description
4 Power supplies
Raisecom Technology Co., Ltd.
20
4.3.3 Interfaces
Table 4-7 lists interface on the SUB-PWRM-AC panel.
Table 4-7 Interface on the SUB-PWRM-AC panel
Print
Description
–
AC interface
4.3.4 LEDs
Table 4-8 lists LEDs on the SUB-PWRM-AC panel.
Table 4-8 LEDs on the SUB-PWRM-AC panel
LED
Status
Description
SYS
Green
System working LED

Blinking green: the system is working properly.

Off: the system is working improperly.
-48V PWR
Green
-48 V power output LED

Green: -48 V power output is normal.

Off: -48 V power output is off.
-48V ALM
Red
-48 V power alarm LED

Red: -48 V power output is off or the voltage is abnormal.

Off: -48 V voltage is normal.
5V PWR
Green
+5V power output LED

Green: +5V power output is normal.

Off: +5 V power output is off.
5V ALM
Red
+5V power alarm LED

Red: +5V power output is off or the voltage is abnormal.

Off: +5V voltage is normal.
100-240V
Green
Power input LED

Green: 110 V/200 V power input is normal.

Off: power input is off.
Min
Yellow
Input voltage hierarchical alarm LED

Yellow: the deviation between the input voltage and the
centered voltage is within range 1.

Off: the deviation between the input voltage and the centered
voltage is beyond range 1.
Maj
Red
Input voltage hierarchical alarm LED

Red: the deviation between the input voltage and the centered
voltage is within range 2.

Off: the deviation between the input voltage and the centered
voltage is beyond range 2.
