Raisecom

iTN2100 (P100R002) Hardware Description

21 Cables

Raisecom Technology Co., Ltd.

266

Card

Cable

CBL-V35-HDB26M/DB25M (unshielded cable)

21.12.2 CBL-V35-HDB26M/2M34F

Appearance

Figure 21-24 shows the CBL-V35-HDB26M/2M34F cable.

Figure 21-24 CBL-V35-HDB26M/2M34F cable

Specifications

Table 21-27 lists specifications of the CBL-V35-HDB26M/2M34F cable.

Table 21-27 Specifications of the CBL-V35-HDB26M/2M34F cable

Parameter

Description

Name

CBL-V35-HDB26M/2M34F

Connector

HDB26 male connector, or M34 female connector

Type

9.5P+1+B+AL cable

21.12.3 CBL-V35-HDB26M/2M34M

Appearance

Figure 21-25 shows the CBL-V35-HDB26M/2M34M cable.
