iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
185
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
ON
OFF
ON
ON
SS13
ON
OFF
ON
OFF
SS15
ON
OFF
OFF
ON
SS23
ON
OFF
OFF
OFF
SS25
SW3 is properly configured before the card leaves the factory. Do not configure it if
not needed.
15.11.6 Alarms
Table 15-65 lists alarms of the OPCOM3500E-240H×2.
Table 15-65 Alarm of the OPCOM3500E-240H×2
Alarm
Cause
Level
Optical interface LOS
alarm

Attenuation of received signals is over great.

The peer sender fails on the interface.

The connector of fiber is dirty or improperly
connected.

The local receiver fails.
Critical
Remote device LPR alarm
The remote device is powered off.
Critical
15.11.7 Specifications
Table 15-66 lists specifications of the OPCOM3500E-240H×2.
Table 15-66 Specifications of the OPCOM3500E-240H×2
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
< 0.45 kg
Max. power consumption
8 W
