iTN2100 (P100R002) Hardware Description
5 NMS card
Raisecom Technology Co., Ltd.
27
LED
Status
Description
100M
(NM-EXT)
Green
NM-EXT interface rate LED

Green: the Ethernet rate is 100 Mbit/s.

Off: the Ethernet rate is 10 Mbit/s.
LNK/ACT
(NM-EXT)
Green
NM-EXT interface working LED

Green: the NM-EXT interface is working properly.

Off: the NM-EXT interface is disconnected or is
working improperly.

Blinking green: the NM-EXT interface is receiving or
sending data.
5.1.6 Alarms
Table 5-6 lists alarms of the iTN2100-NMS.
Table 5-6 Alarms of the iTN2100-NMS
Alarm
Cause
Level
Chassis alarm

The NMS channel between a card and the NMS card fails.

The SDH clock module fails.
Critical
Cold reset
The iTN2100 is reset upon power failure.
Critical
5.1.7 Specifications
Table 5-7 lists specifications of the iTN2100-NMS.
Table 5-7 Specifications of the iTN2100-NMS
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
≤ 0.43 kg
Max. power consumption
10 W
