iTN2100 (P100R002) Hardware Description
10 Ethernet access cards
Raisecom Technology Co., Ltd.
68
LED
Status
Description
LNK/ACT
(1–4)
Green
Link working LED

Green: the link interface is properly connected.

Off: the link interface improperly connected or disconnected.

Blinking green: the link interface is receiving or sending data.
10.4.5 DIP swtiches
Table 10-19 lists configurations of DIP switch SW1 on the OPCOM3500E-4FX.
Table 10-19 Configurations of DIP switch SW1 on the OPCOM3500E-4FX
DIP
switch
Function
Status
Description
Bit1
Bit2
Bit3
Bit4
Optical interface
device
SW1
Set the type
of the
optical
interface
device.
ON
ON
ON
ON
M
ON
ON
ON
OFF
S1
ON
ON
OFF
ON
S2
ON
ON
OFF
OFF
S3
ON
OFF
ON
ON
SS13
ON
OFF
ON
OFF
SS15
ON
OFF
OFF
ON
SS23
ON
OFF
OFF
OFF
SS25
The card is properly configured before leaving factory. Do not configure if not needed.
10.4.6 Specifications
Table 10-20 lists specifications of the OPCOM3500E-4FX.
Table 10-20 Specifications of the OPCOM3500E-4FX
Parameter
Value
Dimensions
25 mm (width) × 232 mm (depth) × 240 mm (height)
Weight
0.4 kg
Max. power consumption
12 W
