Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
20 Service aggregation cards
Raisecom Technology Co., Ltd.
241
Parameter
Value
Max. power consumption
5 W
20.3.6 Optical performance metrics
Table 20-22 lists optical performance metrics of the iTN2100-4SU-D.
Table 20-22 Optical performance metrics of the iTN2100-4SU-D
Parameter
Metric
Central wavelength (nm)
1511, 1531, 1551, 1571
Passband (nm)
±6.5
Channel insertion loss (dB)
(with the connector)
< 2
Adjacent channel isolation (dB)
> 25
Non-adjacent channel isolation (dB)
> 35
Fiber
9/125 µm single-mode fiber
Return loss (dB)
> 45
Directivity (dB)
> 55
Operating temperature of optical module (°C)
-5 to 65
Storage temperature of optical module (°C)
-40 to 85
20.3.7 Networking applications
Point-to-point networking application
Device A multiplexes optical signals of 4 wavelength channels (1511 nm, 1531 nm, 1551 nm,
and 1571 nm) at the client side and transmits the multiplexed signals to Device B. After
receiving optical signals, Device B de-multiplexes these signals and then sends them out. In
opposite direction, Device B multiplexes optical signals of 4 wavelength channels at the client
side and transmits the multiplexed signals to Device A. After receiving optical signals, Device
A de-multiplexes these signals and then sends them out.
Figure 20-3 shows a point-to-point networking application with the iTN2100-4SU-D.
