iTN2100 (P100R002) Hardware Description
6 SDH aggregation card
Raisecom Technology Co., Ltd.
33
Table 6-7 Alarms of the OPCOM3500E-2STM1/4-M
Alarm
Cause
Level
RS-LOS

Attenuation of received signals is over great.

The peer sender fails.

The connector of fiber is dirty or improperly connected.

The local receiver fails.
Critical
RS-LOF

The TX clock of the peer device fails.

Optical signals do not match.

The local RX reference clock fails.
Critical
RS-TIM

The received trace byte of the local device and the sent trace
byte of the peer device are inconsistent.

Services are improperly configured.
Critical
AU-AIS

The AU-AIS alarm of the VC4 channel is triggered by MS-
AIS, R-LOS, or R-LOF alarms.

Services are improperly configured.

The peer device sends AU-AIS alarms.

The TX part of the peer device or the RX part of the local
device fails.
Minor
AU-LOP

The RX part of the peer device fails.

Services are improperly configured on the peer device.

Bit Error Rate (BER) of the local device is over great.
Critical
MS-EXC

BER in the multiplexing section is over high.

Optical signals are improperly transmitted.

The performance of the local card is bad.
Major
MS-AIS
Multiplexing section alarm LED

Alarm signals are inserted in the optical signals sent by the
peer device.

The peer device is a regenerator and receives LOS, LOF, or
OOF alarms.
Minor
HP-LOM
High-order Path (HP) Loss of Multiframe (LOM) alarm

Services are improperly configured.

Byte H4 is lost or incorrect.
Critical
HP-TIM
HP Trace byte (J1) mismatch alarm

The received HPtrace byte of the local device and the sent
HP trace byte of the peer device are inconsistent.

Services are improperly configured.
Critical
HP-PLM
HP signal marking byte (C2) mismatch alarm

The received signal marking byte of the local device and the
sent signal marking byte of the peer device are inconsistent.

Services are improperly configured.
Critical
TU-AIS

Services are improperly configured.

The channel of the peer device fails.

Higher–level alarms, such as R-LOS, trigger the alarm.

The crossconnection card fails, SDH data received from the
backplane is incorrect.
Minor
TU-LOP

The interface between the tributary card and the cross
connection card fails.

Services are improperly configured.
Critical
LP-TIM

The Low-order Path (LP) trace identifiers of the local device
and the peer device are inconsistent.

Services are improperly configured.
Critical
