Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
146
Interface
Status
Description
WKB (L)
Green
Local optical interface B working LED

Green: local optical interface B is the working interface.

Off: local optical interface B is not the working interface.
WKB (R)
Green
Remote optical interface B working LED

Green: remote optical interface B is the working interface.

Off: remote optical interface B is not the working interface.
LOSA (L)
Red
Local optical interface A LOS alarm LED

Red: input LOS alarms are generated on local optical interface
A.

Off: no input LOS alarms are generated on local optical interface
A.
LOSA (R)
Red
Remote optical interface A LOS alarm LED

Red: input LOS alarms are generated on remote optical interface
A.

Off: no input LOS alarms are generated on remote optical
interface A.
LOSB (L)
Red
Local optical interface B LOS alarm LED

Red: input LOS alarms are generated on local optical interface
B.

Off: no input LOS alarms are generated on local optical interface
B.
LOSB (R)
Red
Remote optical interface B LOS alarm LED

Red: input LOS alarms are generated on remote optical interface
B.

Off: no input LOS alarms are generated on remote optical
interface B.
LOF (L)
Red
Local LOF alarm LED

Red: input signal LOF alarms are generated on the local optical
interfaces.

Off: no input signal LOF alarms are generated on the local
optical interfaces.
LOF (R)
Red
Remote LOF alarm LED

Red: input signal LOF alarms are generated on the remote
optical interfaces.

Off: no input signal LOF alarms are generated on the remote
optical interfaces.
E-3 (L)
Red
Local 10-3 error code alarm LED

Red: local input signals have 10-3 error codes.

Off: local input signals have no 10-3 error codes.
E-3 (R)
Red
Remote 10-3 error code alarm LED

Red: remote input signals have 10-3 error codes.

Off: remote input signals have no 10-3 error codes.
E-6 (L)
Yellow
Local 10-6 error code alarm LED

Red: local input signals have 10-6 error codes.

Off: local input signals have no 10-6 error codes.
