Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
15 PDH and RCMS cards
Raisecom Technology Co., Ltd.
151
Interface
Status
Description
LNK/ACT
Green
Line working LED
Green: the interface is working properly.
Off: the interface is disconnected or is working improperly.

Blinking green: the interface is receiving or sending data.
WKA (L)
Green
Local optical interface A working LED

Green: local optical interface A is the working interface.

Off: local optical interface A is not the working interface.
WKA (R)
Green
Remote optical interface A working LED

Green: remote optical interface A is the working interface.

Off: remote optical interface A is not the working interface.
WKB (L)
Green
Local optical interface B working LED

Green: local optical interface B is the working interface.

Off: local optical interface B is not the working interface.
WKB (R)
Green
Remote optical interface B working LED

Green: remote optical interface B is the working interface.

Off: remote optical interface B is not the working interface.
LOSA (L)
Red
Local optical interface A LOS alarm LED

Red: input LOS alarms are generated on local optical
interface A.

Off: no input LOS alarms are generated on local optical
interface A.
LOSA (R)
Red
Remote optical interface A LOS alarm LED

Red: input LOS alarms are generated on remote optical
interface A.

Off: no input LOS alarms are generated on remote optical
interface A.
LOSB (L)
Red
Local optical interface B LOS alarm LED

Red: input LOS alarms are generated on local optical
interface B.

Off: no input LOS alarms are generated on local optical
interface B.
LOSB (R)
Red
Remote optical interface B LOS alarm LED

Red: input LOS alarms are generated on remote optical
interface B.

Off: no input LOS alarms are generated on remote optical
interface B.
LOF (L)
Red
Local LOF alarm LED

Red: input signal LOF alarms are generated on the local
optical interfaces.

Off: no input signal LOF alarms are generated on the local
optical interfaces.
