Raisecom iTN2100 User Manual

Raisecom
iTN2100 (P100R002) Hardware Description
20 Service aggregation cards
Raisecom Technology Co., Ltd.
223
SFP
module
SFP module model
Central TX
wavelength
(nm)
TX
power
(dBm)
Overload
power
(dBm)
RX
sensitivity
(dBm)
Transmis
sion
distance
(Km)
USFP-Gb/S1-D-R
1310
-10 to -3
> -3
< -21
15
USFP-Gb/LH1-D-R
1310
-4 to 0
> -3
< -21
40
USFP-Gb/S2-D-R
1550
-3 to +2
> -3
< -21
60
USFP-Gb/ZX-D-R
1550
-2 to +3
> -3
< -22
80
USFP-Gb/S3-D-R
1550
-3 to +2
> -9
< -30
80
USFP-Gb/EX-D-R
1550
0 to +5
> -9
< -31
120
USFP-Gb/SS13-D-R
1310
-10 to -3
> -3
< -21
15
USFP-Gb/SS15-D-R
1550
-10 to -3
> -3
< -21
15
USFP-Gb/SS24-D-R
1490
-3 to +2
> -3
< -21
40
USFP-Gb/SS25-D-R
1550
-3 to +2
> -3
< -21
40
USFP-Gb/SS34-D-R
1490
-2 to +3
> -9
< -30
80
USFP-Gb/SS35-D-R
1550
-2 to +3
> -9
< -30
80
CSFP-Gb
CSFP-Gb/S/xx-D-R
(xx = 47, 49, 51, 53,
55, 57, 59, 61)
1471, 1491,
1511, 1531,
1551, 1571,
1591, 1611
-2 to +3
> -3
< -22
40
CSFP-Gb/L/xx-D-R
(xx = 47, 49, 51, 53,
55, 57, 59, 61)
1471, 1491,
1511, 1531,
1551, 1571,
1591, 1611
-3 to +2
> -9
< -30
80
USFP-48
USFP-48/M-D-R
850
-9.5 to -3
> 0
< -17
0.3
USFP-48/S1-D-R
1310
-5 to 0
> -3
< -18
15
USFP-48/S2-D-R
1550
-2 to +3
> -3
< -18
40
USFP-48/S3-D-R
1550
-2 to +3
> -9
< -28
80
USFP-48/SS13-D-R
1310
-5 to 0
> -3
< -18
15
USFP-48/SS15-D-R
1550
-5 to 0
> -3
< -18
15
USFP-48/SS24-D-R
1490
-2 to +3
> -3
< -18
40
USFP-48/SS25-D-R
1550
-2 to +3
> -3
< -18
40
USFP-48/SS34-D-R
1490
0 to +5
> -9
< -26
80
USFP-48/SS35-D-R
1550
0 to +5
> -9
< -26
80
