iTN2100 (P100R002) Hardware Description
21 Cables
Raisecom Technology Co., Ltd.
273
HDB26F
HDB26M
PIN
Line color
Pair color
21
GND6
Grey/White
White/Grey
4
TXD-5
Grey/Red
Red
14
RXD-5
Red/Grey
5
TXD-4
Brown/Red
15
RXD-4
Red/Brown
6
TXD-3
Orange/Red
16
RXD-3
Red/Orange
7
TXD-2
Green/Red
17
RXD-2
Red/Green
8
TXD-1
Blue/Red
18
RXD-1
Red/Blue
22
GND5
Grey/Black
Black
Black/Grey
23
GND4
Brown/Black
Black/Brown
24
GND3
Orange/Black
Black/Orange
25
GND2
Green/Black
Black/Green
26
GND1
Blue/Black
Black/Blue
19
RXD-8
Blue/Yellow
Yellow
Yellow/Blue
9
–
–
–
10
–
–
–
