System programming in expert mode
Administration and maintenance
A31003-K16-X001-3-7620
,
07/99
7-22
Hicom 100 E Version 2.1, Service manual
22 Codes
22 1 1 1 Substitute code *, code 75
22 2 2 2 Substitute code #, code 76
22 3 3 3 Line code, select line 1–32 and enter new code (max. 3 characters:
801–832)
22 4 4 4 Route code, select route 1–4, then code position 1–10 (max. 10
codes for one route) and enter a new code (max. 5 characters)
22 5 5 5 CO code of main PBX, select route 1–4 and enter new code (max.
2 characters)
23 Doorphone setup
23 1 1 1 Entrance telephone, enter ext. number (max. 5 characters)
Door 1–4 as of SW 2.0.2
23 2 2 2 Receiving extension for doorbell, enter extension or group number
(max. 5 characters)
Door 1–4 as of SW 2.0.2
23 3 3 3 Door opener, 0 = off/1 = on
also 2 = on with DTMF, door 1–4, as of SW 2.0.2
23 4 4 Doorbell divert, external 0 = disable/1 = enable
23 5 5 DTMF door release, 0 = disabled/1 = enabled
Codes Function
ABC
A
= SW 2.0.1+;
B
= SW 2.0.2;
C
= SW 2.1
Table 7-4 Codes for expert mode
