System programming in expert mode
Administration and maintenance
A31003-K16-X001-3-7620
,
07/99
7-24
Hicom 100 E Version 2.1, Service manual
25 Actuators
25 1 1 1 Type, select actuator 1–4 and assign function:
1 = manual (by means of a code) on and off
2 = automatic off after timeout
3 = door opener
4 = loudspeaker/amplifier (trigger contact for amplifier)
5 = busy indicator
6 = music on hold
7 = call charge pulse
8 = second ringer
9 = active extension (as of SW 2.0.2)
25 2 2 2 Response time
select actuator 1–4 and enter max. 3 digit(s) (0-255)
25 3 3 3 Assigned ext.
select actuator 1–4 and enter ext. number
25 4 4 4 Actuator names, select actuator 1–4, enter alphanumeric names
(max. 16 characters)
Codes Function
ABC
A
= SW 2.0.1+;
B
= SW 2.0.2;
C
= SW 2.1
Table 7-4 Codes for expert mode
