Page #202 background imageLoading...
Page #202 background image
Further notes
You define a VLAN as a private VLAN and specify the PVLAN type with the command
private-vlan.
You display this setting with the show vlan private-vlan command.
6.1.4.11 private-vlan association
Description
With this command, you assign secondary PVLANs to a primary PVLAN.
Requirement
The interface is configured as a primary PVLAN.
You are in the Interface configuration mode.
The command prompt is:
cli(config-if-$$$)#
Syntax
Call up the command with the following parameters:
private-vlan association [{add|remove}] <secondary_Vlan_list>
The parameters have the following meaning:
Parameter Description Range of values / note
add Adds a secondary PVLAN.. -
remove Removes a secondary PVLAN.. -
secondary_Vla
n_list
Number of the secondary PVLAN Separate the PVLANs with commas
if you specify several PVLANs.
Result
The secondary PVLANs are assigned to the primary PVLAN.
Further notes
You delete the link between secondary PVLANs and a primary PVLAN with the command no
private-vlan association.
You display this setting with the show interfaces command.
You configure a an interface as a primary PVLAN with the private-vlan command.
Network structures
6.1 VLAN
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
202 Configuration Manual, 07/2017, C79000-G8976-C361-06
