The parameters have the following meaning:
Parameter Description Range of values / note
blocked The forwarding of loop detection frames
is blocked.
-
forwarder Loop detection frames from other devi‐
ces are forwarded.
Default after enabling loop detec‐
tion.
sender Loop detection frames are sent out and
forwarded.
-
If you do not select any parameters from the parameter list, the default value is used.
Result
It has been configured how the port handles loop detection frames.
Further notes
You can display the status of this function and other information with the show loopd
command.
12.6.3.2 loopd {tx-interval | detect-threshold | reaction-timeout}
Description
With this command you configure the send interval, threshold value and reaction time for loop
detection.
Requirement
● Loop detection is enabled
● You are in the Interface configuration mode.
The command prompt is:
cli(config-if-$$$)#
Syntax
Call up the command with the following parameters:
loopd {tx-interval <mSec(500-5000)> | detect-threshold
<integer(1-500)> | reaction-timeout <seconds(0-86400)>}
The parameters have the following meaning:
Parameter Description Range of values / note
tx-interval Keyword for the send interval -
mSec Specifies the send interval for loop de‐
tection frames in milliseconds.
500 ... 5000
Default: 1000
Diagnostics
12.6 Loop detection
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
604 Configuration Manual, 07/2017, C79000-G8976-C361-06
