Siemens SCALANCE XR-300WG User Manual

Industrial Ethernet profile
● Industrial Ethernet protocol: PROFINET
● Base Bridge mode: 802.1Q VLAN Bridge
● Redundancy mechanism: RSTP
● Trust mode: Trust COS-DSCP
Purpose of the Configuration Manual
This Configuration Manual is intended to provide you with the information you require to install,
commission and operate IE switches. It provides you with the information you require to
configure the IE switches.
Orientation in the documentation
Apart from the configuration manual you are currently reading, the products also have the
following documentation:
● Configuration manual "SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Web
Based Management""
This document is intended to provide you with the information you require to commission
and configure IE switches using the Web Based Management.
● Operating Instructions "SCALANCE XB-200", "SCALANCE XC-200", "SCALANCE
XF-200BA", "SCALANCE XP-200" and "SCALANCE XR-300WG"
These documents contain information on installing, connecting up and approvals for the
products.
You will find the documentation here:
● On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
● On the Internet pages of Siemens Industry Online Support at.
– SCALANCE XB-200 (https://support.industry.siemens.com/cs/ww/en/ps/15291/man)
– SCALANCE XC-200 (https://support.industry.siemens.com/cs/ww/en/ps/24185/man)
– SCALANCE XF-200BA (https://support.industry.siemens.com/cs/ww/en/ps/15287/
man)
– SCALANCE XP-200 (https://support.industry.siemens.com/cs/ww/en/ps/21869/man)
– SCALANCE XR-300WG (https://support.industry.siemens.com/cs/ww/en/ps/15296/
man)
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will find information on other
SIMATIC NET products that you can operate along with the devices of this product line in an
Industrial Ethernet network.
Introduction
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
22 Configuration Manual, 07/2017, C79000-G8976-C361-06
