Parameter Description Range of values / note
interface-type Type or speed of the interface Enter a valid interface.
0/a-b,0/c,... Module no. and port no. of the interface
vlan Keyword for a VLAN connection
● In the "VLAN Bridge" mode
Enter a valid VLAN or VLAN
range.
● In the "Transparent Bridge"
mode:
The configurations relating to
VLANs are ignored. The rules
apply to all VLANs.
If you have defined certain
VLANs with a firmware version
< 1.2, the configuration of the
VLANs will be replaced during
a firmware update with the
default value "1-4094".
a,b or a-b or
a,b,c-d
Number of a VLAN or VLAN range
service Specifies the services for which the
manager is authorized.
You can select several options.
● snmp
● telnet
● http
● https
● ssh
For information on names of addresses and interfaces, refer to the section "Addresses and
interface names (Page 36)".
The IP address 0.0.0.0 means "any manager".
If optional parameters are not specified when configuring, the manager is authorized for all
services.
Note
Configuration of the first entry
As long as the list of authorized managers is empty, access to the system is not restricted.
As soon as the list contains an entry and the "authorized-manager" command is executed,
access to the system is blocked for all others.
You should therefore configure the interface via which you access the system first because
your access is otherwise blocked.
Security and authentication
11.3 Management Access Control List
SCALANCE XB-200/XC-200/XF-200BA/XP-200/XR-300WG Command Line Interface
Configuration Manual, 07/2017, C79000-G8976-C361-06 515
