Adjusting knitting machine 4
Basic settings
Adjusting yarn carriers
4.1.3 Adjusting yarn carriers
Adjusting yarn carriers
Adjusting yarn carriers
Keys for adjusting the yarn carriers
Keys for adjusting the yarn carriers
Yarn carrier window
"Yarn carrier" window
Data in the Yarn carrier window
Key
Function
Call up the "Yarn carrier" window
Call up the "Adjusting yarn carrier" window
Call up "Additional function keys"
Call up desired knitting area
Confirm entries
Column
Data shown
Y
Specification of yarn carrier
SEN
Specification of SEN area in which yarn carrier works
Y: =n
Specification of yarn type
0/1
Yarn type switched on or off
YG
Home position of the yarn carrier for needle. . .
YP
Current yarn carrier position for needle. . .
Ka
Yarn carrier correction value (left) for not swiveled yarn carrier if the
yarn
carrier is positioned within the fabric.
Value range: -120...0...120 . Step width: 0.5=1/32 inch=0.8 mm
