Maintenance of the knitting machine 6
Lubricate knitting machine
Oiling yarn carrier rods
6.3.7 Oiling yarn carrier rods
Oiling the yarn carrier rods
Oiling the yarn carrier rods
1. Use a brush or a spray bottle to apply oil to the yarn carrier rods (1).
2. If intarsia yarn carriers are used, wipe off
the oil with a cloth until the notch
on the yarn carrier rod (2) is only coated with a residual lubricating film.
Oiling the control of the holding-down jacks
6.3.8 Oiling the control of the holding-down jacks
➜ Apply oil on the control of the holding-down jacks with a brush.
Oiling carriage guide rail
6.3.9 Oiling carriage guide rail
Oiling the carriage guide bar
Oiling the carriage guide bar
➜ Use a cloth to apply oil to the carriage guide bar (1).
