7 Repairing the knitting machine
Eliminating faults in electronics system
Overview of the electronic control (control cabinet left a nd right)
7.4.2 Overview of the electronic control (control cabinet left
and right)
The machine control is located in the left and right control cabinet under the
covers. The card for controlling the yarn carrier magnets is located in the
carriage.
Valid for:
Type
CMS 803
655
657
CMS 830 C
631
CMS 822
623
632
