227
Adjusting knitting machine 4
Advanced adjustments
5. In order to laterally adjust the position of the yarn carrier tip, bend the yarn
carrier bow carefully (without using force) with the adjusting part (3).
Further information:
Symbols in this document [16]
Intarsia yarn carrier * [36]
Mount intarsia yarn carrier * [427]
Shifting intarsia yarn carriers in area of carriage assembly *
4.2.21 Shifting intarsia yarn carriers in area of carriage
assembly *
Intarsia yarn carriers located in the area of the carriage assembly cannot be
shifted by hand. They are shifted with the shifting device from the accessories.
Shift yarn carriers in area of carri
age assembly:
Shifting device
Shifting device
➜ Press the lifters inward with the shifting device from the accessories and
shift one or more yarn carriers out of the area of the carriage assembly.
Further information:
Symbols in this document [16]
