427
Repairing the knitting machine 7
Replacing parts
Mount intarsia yarn carrier *
7.3.17 Mount intarsia yarn carrier *
Combination possibilities for normal and Intarsia yarn carriers:
Normal yarn carrier
type 1
Normal and intarsia yarn carriers can be used side by side but
no
t on the same track.
Reason: The disengaging arms (1) of the normal yarn carrier
collide with the intarsia yarn carrier or the yarn carrier limiter.
The combination possibilities:
Each combination can be used with itself or with another
combination.
: Equip the yarn carrier tracks from inward to outward.
With the allocation from inward to outward no track must be kept
empty when using intarsia and normal yarn carriers.
Normal yarn carrier
type 2
Normal yarn carriers type2 and intar
sia yarn carriers can be
used together on the same track.
The combination possibilities:
You can equip the yarn carrier rails as desired.
You c
an equip all the tracks.
