80
3 Producing with the knitting machine
Preparing production and shift changes
Setting touch screen
3.1.3 Setting touch screen
Calibrating t ouch screen
Calibrating touch screen
The calibration is particularly important when persons of different heights work
at the same machine. In the case of different viewing angles, the position of
the keys may change. So that you always press the proper keys, calibrate the
touch screen at the beginning of your shift.
Keys for calib rating the to uch screen
Keys for calibrating the touch screen
Calibrating touch screen:
1. Call up the "Service" menu from the "Main menu".
2. Call up the "Set the touch screen" window from the
"Service" menu.
Key
Function
Call up the "Service" menu
Call up the "Set touch screen" window.
"Calibrate" key
Call up "Main menu"
NOTICE
Incorrect adjustment of the touch screen!
Permanent incorrect adjustment: If you set the touch sc
reen
incorrectly, the keys on the screen are no longer accessible.
The program can only be readjusted with a keyboard (Stoll
helpline).
➜ Durin
g calibration, touch the touch screen within the target
circles only!
