212
4 Adjusting knitting machine
Advanced adjustments
Correcting position of stitch cams
4.2.11 Correcting position of stitch cams
Each stitch cam can be corrected for each carriage direction
for knitting
for knitting with split-stitch tech
nique
Reduce stitch tension: Value without sign or with "+"
sign
Increase stitch tension: Value
with "-" sign
The second stitch cam of a system is always corrected, as only it is
active.
The stitch cams are numbered consecutively from left to right, regardless of
the carria
ge direction.
Meaning of displays in NPK values window
Meaning of displays in NPK values window
Meaning
System 1 - n
Number of knitting system counted from left to right
<<
Carriage direction to the left
>>
Carriage direction to the right
n.n
Correction value for knitting
$ n.n
Correction value for knitting with split-stitch technique
