7 Repairing the knitting machine
Needle selection displacement
Determining the needle selection displacement manually
7.6.4 Determining the needle selection displacement
manually
Keys for determining the needle selection displacement
Keys for determining the needle selection displacement
Determine the needle selection displacement:
1. Fix knitting row.
For checking the front impulse sensor enter "SPF30".
2. Engage the machine, stop the car
riage in the
right reversing point.
3. Call up the "Service" menu from the "Main menu".
4. Call up "Basic Settings" menu.
5. Call up the "Adjustment of needle selection" menu.
6. Call up the "Manually coarse" menu.
Key Function
Call up the "Service" menu
Call up the "Basic settings" menu
Call up the "Adjustment of needle selection" menu
Call up the "Automatic" menu
Call up the "Manually coarse" menu
