4 Adjusting knitting machine
Advanced adjustments
Adjusting sensor mechanism *
4.2.3 Adjusting sensor mechanism *
Sensors w indow
"Sensors" window
* does not apply in case of machines with belt take-down
Field
Data shown
1
Stop by Resistance
Value range: 1-32, 1=not sensitive, 32=very sensitive
2
Carriage speed after small knots
3
Activating/deactivating of horn and selection of volume in three
degrees:
0=off 1=low, 2=middle, 3=loud
Intermittent Tone
Switching on/off an intermitt
ent tone for th
e horn.
Interval (sec)
The time (pause) between two intervals is adjustable (max. 60
seconds).
4 *
If the comb take-down moves upward for fabric transfer, a light
barrier checks whether the previously produced knitted panel
has completely been ejected.
5 *
Monitoring of main take-down. If the fabric take-down roller has
not turned after "n" (0-100) knitting rows, a stop motion is carried
out (0=monitoring off).
6 *
Monitoring of main take-down. If the roller turns too quickly, a
stop motion is carried out (e.g. when the fabric is ejected). Value
range: 1-32, 1=not sensitive, 32=very sensitive
7 *
Monitoring of auxiliary take-down. If the auxiliary take-down has
not turned after "n" (0-100) knitting rows, a stop motion is carried
out (0=monitoring off).
