173
Adjusting knitting machine 4
Basic settings
Configuring monitoring
4.1.18 Configuring monitoring
The current Sintral line and the corresponding values for the cycle counters,
Jacquards, stitch tension and counters are displayed in the "Changeable
monitoring" window for each carriage stroke during productions.
You can specify yourself which valu
es ar
e to be displayed or have them
determined automatically. (Exception: Those counters and repeat switches
which are used exclusively in the Auto-Sintral program are not displayed.)
Changeable monitoring window
"Changeable monitoring" window
Field
Function
1
Display of the current Sintral line
2
White field with frame. The field can be linked to a value. The
value is then displayed in this field.
A thick frame around the field indicates that it cannot be covered
by a function block (4).
3
Gray field. If a field (2) is limited to a value, the color changes
from white to gray.
4
White field without frame. This is a function block. The display of
a function block can be activated and deactivated.
