Stoll CMS 520 C+ - Stitch Lengths

329
Setup Data 5
Setup2 Editor
Stitch lengths
5.5.4 Stitch lengths
NP 1-100 (tab)
NP 1-100 (tab)
NP 1-100 (tab) stp
Further information:
 Table Tools [316]
 File tools [317]
 Helpers for Input [311]
 Overview of the Setup2 Editor
of the CMS [
309]
Explanation Value range
NPK Correction for all stitch cams Minimum value: -2
Maximum value: 2
Step width: 0.05
NP1 -
NP100
Stitch cam position 1 to 100
Value Stitch length in NP values or mm
Value [mm] Specification in NP values. Minimum value: 6.5
Maximum value: 22.5
Step width: 0.05
Value [mm] Settings in millimeters.
Setting the yarn length per stitch (Yarn
Length Control).
Minimum value: 2.20
Maximum value: 33.00
Step width: 0.01
Comment Comment ASCII Characters
