307
Setup Data 5
Using Setup1 or Setup2
Using Setup1 o r Setup2
5.3 Using Setup1 or Setup2
How to generate a setup-file?
Generating it together with the pattern on
the M1plus.
Starting with the 5.2 version of the
M1plus you can choose among Setup
in Sintral, Setup1, Setup2
Generating it manually (with Setup1 only)
Setup1
usable for all machines
(OKC, ST 468, ST 268, ST 168, ST 811, ST 711)
Setup2
usable with all OKC machines (starting with V 2.1)
Converting
Setup2 -->
1
Possible with M1plus (starting with V. 5.2) only.
Example:
How to convert a Setup2 patter for a CMS 530 to a pattern
for a
CMS 330:
1. Load the pattern and call up the
"Change Machine/
Gauge/Setup Type..." menu.
2. Set the corresponding setup type for the machine in the
"Machi
ne Explorer".
3. Start technical processing.
or
4. Run the "Generate MC Program..." function.
5. Run the "Extract MC
Program..." func
tion.
The sin; jac and set files will be generated.
Converting
Setup1 -->
2
Setup1 patterns cannot be converted automatically into
Setup2.
Example:
How to convert a Setup1 pattern for a CMS 330 to a Setup2
patter
n for
a CMS 530:
1. Load the pattern and call up the
"Change Machine/
Gauge/Setup Type..." menu.
2. Set the corresponding setup type for the machine in the
"Machi
ne Explorer".
3. Modify and complete the parameters and functions
corres
ponding to Setup2.
4. Start technical processing.
or
5. Run the "Generate MC Program..." function.
6. Run the "Extract MC
Program..." func
tion.
The sin; jac and setx-files will be saved to a zip-file.
