Stoll CMS 520 C+ - Racking Correction

185
Adjusting knitting machine 4
Basic settings
Racking correction
4.1.20 Racking correction
To achieve the optimum delivering position even with different stitch tensions,
the racking specification can be provided with a correction. Usually, the
correction value is provided with a "?" when writing the knitting program.
During knitting, the machine automat
ically stops in
the reversing position
before the line with the correction specification is knitted. Now the optimum
value can be entered.
Button for calling u p the Racking cor rection wi ndow
Button for calling up the "Racking correction" window
Adjusting racking correction value:
1. Call up the "Racking correction" window
from the "Main menu".
2. Press the input field for the racking correction and enter the value.
- or
-
➜ If a racking correction is to be changed, then tap the correspondi
ng button
and enter the value in the input field.
3. Confirm input.
Key Function
Call up the "Racking correction" window
Confirm entries
