186
4 Adjusting knitting machine
Basic settings
Racking correction (Setup2)
Racking correction (Setup2)
Racking correction (machine without additional needle bed)
Explanation
Value range
VCI…
Racking function
VCI1 to VCI50
VK
Racking correction by m steps (0-
10)
Step width: 1/70 of the
needle distance
Dir
Direction of the racking correction
< - to the left
> - to the right
?
- not defined, will be defined on
the machine
VV
Racking speed n (1-32), without
an instruction VV=32
V+/-
V+ - Overracking, in addition to
the racking specification
positive value: Overracking in
racking dire
ction
negative value: Overracking in
opposite to the racking direction
(n=1-24, step width: 1/8 of
the needle distance)
Comment
Comment
ASCII Characters
