355
Maintenance of the knitting machine 6
Cleaning the knitting machine
Cleaning fan and radiators in right control unit
6.2.10 Cleaning fan and radiators in right control unit
1. Switch off the machine and wait until the machine is currentless.
2. Swing open the cover on the right-han
d control unit.
Control unit
Control unit
3. Vacuum-off and blow-out the fan (1) and heat sink (2).
4. Close the cover on the right con
trol unit.
5. Switch on machine.
Cleaning filter mat of power supply unit
6.2.11 Cleaning filter mat of power supply unit
1. Swing open the cover on the control unit.
Fan power su pply unit
Fan power supply unit
2. Remove screw (1) and hinge down the housing toward the front.
3. Remove filter mat and blow it out with compressed air.
4.
If heavy soiling is present, vacuum off and
blow out the radiator (2).
5. Replace filter mat.
6. Swing in the cover on the left control unit.
The fan is temperature-controlled.
