Stoll CMS 520 C+ - Eliminating Faults in Electronics System; Overview of the Electronic Control (Control Cabinet Right)

439
Repairing the knitting machine 7
Eliminating faults in electronics system
Eliminating faults in electronics sy stem
7.4 Eliminating faults in electronics system
This chapter contains information on:
 Overview of the electronic control (contr
ol cabinet right) [439]
 Overview of the electronic control (control cabine
t left and right) [442]
 Power supply unit [445]
 Control of yarn carrier magnets [445]
 Replacing electronic card [446]
Overview of the electronic control (control cabinet right)
7.4.1 Overview of the electronic control (control cabinet right)
The machine control is located in the right control cabinet under the cover. The
card for controlling the yarn carrier magnets is located in the carriage.
Valid for:
Type
CMS 530 642
643
CMS 520 C 652
CMS 502 658
668
