Stoll CMS 520 C+ - Comparing Setup1 to Setup2

305
Setup Data 5
Comparing Setup1 to Setup2
Comparing Setup1 to Setup2
5.2 Comparing Setup1 to Setup2
Setup1 Setup2
Fabric take-down
functions (WMF)
8 functions 50 fabric take-down
functions (WMF)
50 Auxiliary take-down
functions (W+F)
Switching auxiliary take-
down on and off (W+1,
W+0)
Tabs for WM% and
WMK%
Belt take-down functions
(WBF)
Not possible 50 belt take-down
functions (WBF)
Yarn Carrier Staggering
YD
One staggering (YD) 21 staggerings
(YD, YDI1-YDI20)
Yarn carrier corrections One correction 20 corrections
(YCI1-YCI20)
Some corrections for all
32 yarn carriers can be
defined with each
function.
◆ The Setup file does not
contain the correction
of the normal yarn
carriers.
◆ Correction of Intarsia
yarn carrier in the KI /
K<I> tab
All yarn carrier
corrections (normal and
intarsia yarn carriers)
are included in the YCI
tab
with tandem mode:
the correction values for
the right carriage are
part of the Y:Oa-b tab
Correction values for
stitch cam position (NP)
100 100
Specifications for the
carriage speed (MSEC)
9 20
Correction value for
clamping depth (NCC)
no part of the setup-file A correction value per
yarn carrier is possible
Yarn length Indications for yarn
length control on the
right
Indications for yarn
length control on the
right and left
