Adjusting knitting machine 4
Basic settings
Setting stitch tension
4.1.2 Setting stitch tension
The stitch tension and thus the stitch size depend on the stitch cam values. It
is possible to specify either the stitch tension as an absolute value or the stitch
length.
Keys for setting the stitch tensi on
Keys for setting the stitch tension
Setting stitch tension:
1. Call up the "Stitch length" window.
2. With Setup1: Set the switch in the "NP value/(mm)" field to "NP value" or
"(
mm)".
3. With Setup1 and Setup2:
Tap on the input field that is to be edited and enter the value.
4. Confirm entries.
5. Call up "Main menu".
Further information:
Stitch Tension Range [513]
Stitch lengths [515]
Economic production and the influe
ncing factor
s [511]
Key
Function
Call up "Stitch length" window
Confirm entries
Call up "Main menu"
