Stoll CMS 520 C+ - Yarn Carrier

323
Setup Data 5
Setup2 Editor
Yarn carrier
5.5.3 Yarn carrier
YD / YDI (tab)
YD / YDI (tab) Staggering the yarn carriers at the fabric selvedge.
YD/YDI (Setup2)
Further information:
 Table Tools [316]
 File tools [317]
 Helpers for Input [311]
 Overview of the Setup2 Editor
of the CMS [
309]
 Setup Data [303]
 Comparing Setup1 to Setup2 [305]
Explanation Value range
YD Distance between yarn carriers and
fabric selvedge
Collapse (reduced display)
Expand
(expanded display)
YD1
:
YD8
Distance of the yarn carriers on track 1
to 8 from the left and right fabric
selvedge
CMS ADF:
YD1…YD16, track 1 to
track 16
Minimum value: 0
Maximum value: 160
Step width:
0.5=1/32 inch=0.8 mm
YDI Additional, indirect yarn carrier
staggering (YDI1 to YDI20)
Collapse (reduced display)
Expand
(expanded display)
Minimum value: 0
Maximum value: 160
Step width:
0.5=1/32 inch=0.8 mm
Comment Comment ASCII Characters
