5 Setup Data
Setup2 Editor
YC / YCI (tab)
YC / YCI (tab) Yarn carrier corrections
Setup2-YC/YCI
Explanation
Value range
YC
Direct yarn carrier correction
Collapse (reduced display)
Expand
(expanded display)
YCI
Yarn carrier correction index YCI1 to
YCI20
Collapse (reduced display)
Expand
(expanded display)
Y
Corrections of yarn carrier 1A to 8D
Ka
Yarn carrier correction value (left) for not
swiveled yarn carrier if the yarn carrier is
positioned within the fabric.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
Kb
Yarn carrier correction value (right) for
not swiveled yarn carrier if the yarn
carrier is positioned within the fabric.
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
K<I>a
Intarsia yarn carrier correction value
(left) for swiveled intarsia yarn carrier
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
K<I>b
Intarsia yarn carrier correction value
(right) for intarsia swiveled yarn carrier
Minimum value: -120
Maximum value: 120
Step width:
0.5=1/32 inch=0.8 mm
MSEC
Carriage speed if this yarn carrier is
used (technical fabrics).
V
Reduce carriage speed (n) for yarn
carrier (n = 0..3). The speed is reduced
to 75% from carriage reversal point until
achievement of the operating range of
the yarn carrier. Finally it can be chosen
between the following possibilities:
◆
1 = Acceleration up to 100%
◆ 2 = Braking down to 50%, maintain
speed over a fabric width of 2 inches,
acceleration up to 100%
◆ 3 = Braking down to 50%, maintain
speed over a fabric width of 5 inches,
acceleration up to 100%
◆ 0 = Cancelling out of carriage speed
specific to yarn carrier
