4 Adjusting knitting machine
Advanced adjustments
Adjusting racking position correctio n VPK
4.2.9 Adjusting racking position correction VPK
The fine adjustment of the transfer racking is carried out by means of the VPK
value. With the "Racking position correction (VPK)" the rear needle bed is
aligned exactly relative to the front needle bed.
The VPK value always remains saved, e
ven if the operat
ing system is
imported again.
Difference between "Racking position c orrection VPK" and "R acking correction" (5 xx, 9xx, TC-S)
Keys for setting VPK value
Keys for setting VPK value
Adjusting VPK:
1. Program an empty row with transfer racking and fix the knitt
ing
specification [378].
2. Push up two opposing needles in the center of the ne
edle bed.
Difference between "Racking position correction VPK" and "Racking
correction"
VPK
racking position
correction
The VPK value changes the position of rear
needle bed - a change has effect on all racking
positions.
VKA -
VKZ
Racking
correction
If you want to correct a specific racking position
in the pattern, carry out a racking correction
(see [185]).
Key
Function
Call up the "Service" menu
Call up the "Service Racking" window
Confirm input
Call up "Main menu"
